A36 welded steel pipe is a stitched steel pipe. The production process is to bend the pipe blank (steel plate and steel strip) into a steel pipe with the required cross-sectional shape and size using various forming methods, and then use different welding methods to weld the welds together to obtain the steel pipe.

Отправить запрос

Теперь говорите

Внедрение продукции

A36 Structural Pipe Description

A36 steel pipe standard is suitable for riveted, bolted and welded structures used in bridges and buildings, as well as general purpose structural steel quality carbon steel. The yield value of A36 steel pipe is around 240MP, and its yield value decreases as the thickness of the material increases. Due to its moderate carbon content, it has good comprehensive properties, and its strength, plasticity and welding properties are well matched, and it is the most widely used.

A36 SSAW Pipe Specification:

	1 Ton
	1-5 Tons US $424/ Ton;>5 Tons US $401/ Ton

	15-25 work days

	200000 Tons/year

Size Of A36 SSAW Steel Pipe


219	4-8	558.8	4-12	914.4	8-16
273	4-8	609.6	4-12	965.2	8-16
325	4-8	630	4-12	1020	8-16
377	4-8	711.2	4-13	1220	8-16
406	4-12	720	8-13	1420	8-20
426	4-12	762	8-14	1620	8-20
478	4-12	812.8	8-14	1820	8-20
508	4-12	863	8-14	2020	8-20

Mechanical Property for A36 Steel Pipe:


T Less than or equal to 200	250	400-550	200mm	50mm
200	220	400-550	20	23

Chemical Composition for A36 Steel Pipe (Heat Analysis Max%)

Main chemical elements composition of A36 steel pipe
	C			P	S
T Less than or equal to 20	0.25	0.40	...	0.04	0.05	0.20
20			0.80-1.20
40	0.26	0.15-0.40
65	0.27		0.85-1.20
100	0.29

SSAW A36 Pipe

ssaw pipe large A36 pipe

GNEE Group is one of China's well-known steel pipe suppliers. It is a large-scale steel supply chain group integrating spiral steel pipes, seamless steel pipes, straight seam steel pipes, thermally expanded steel pipes, oil casings, pipe fittings, steel pipe anti-corrosion and insulation and other steel pipe products. Obtained multiple qualification certifications.
The company now has four double-sided submerged arc spiral welded steel pipe production lines, using advanced Lincoln welding machines, which can produce 219-2820*5-30mm spiral pipes; three medium-frequency thermal expansion steel pipe production lines, which can produce 219-820mm, wall thickness 6mm-30mm , Steel grade Q235B, 20#, Q345B, X42, X52, X65 seamless pipe, straight seam pipe. Products comply with GB, American ASTM, API, ANSI, JIS, DIN and other standards; anti-corrosion insulation production line, can produce various types of steel pipes and single and double-layer soluble epoxy powder (FBE), double-layer polyethylene (PE) 2, three-layer Pipeline projects such as polyethylene (PE), double-layer polypropylene (PP) 2, 3-layer polypropylene (PP), epoxy coal pitch anticorrosive coating, IPN8710 polymer anticorrosive coating, cement mortar lining, PU insulation, etc., implement SY/T4013 -2002, SY/T0315-97, DIN30670, DIN30671 standards. If you have any needs for steel pipes, you can contact us at any time and provide the products and specifications you need, and we will provide you with a quotation as soon as possible.
